DIN 5510 Certification GPO3 Red Laminate Sheet , Fiberglass Plate Sheet

DIN 5510 Certification GPO3 Red Laminate Sheet , Fiberglass Plate Sheet

    • DIN 5510 Certification GPO3  Red Laminate Sheet , Fiberglass Plate Sheet
    • DIN 5510 Certification GPO3  Red Laminate Sheet , Fiberglass Plate Sheet
    • DIN 5510 Certification GPO3  Red Laminate Sheet , Fiberglass Plate Sheet
  • DIN 5510 Certification GPO3  Red Laminate Sheet , Fiberglass Plate Sheet

    Product Details:

    Place of Origin: China Xiamen
    Brand Name: Hongcheng
    Certification: DIN5510 / EN45545
    Model Number: GPO-3

    Payment & Shipping Terms:

    Payment Terms: T/T
    Supply Ability: 100 pcs per day
    Contact Now
    Detailed Product Description
    Product Name:: HC-GPO3 Product Color:: Red、White、Brown、Gray
    Thickness: 0.5mm-80.0mm Product Size: 1000*1200;1000*1300;1230*2100
    Impact Strength: ≥60KJ/m2 Volume Resistivity: ≥ 1.0 X 1010 Ω·m
    Surface Resistivity: ≥ 1.0 X 1012 Ω Electric Strength ┴: ≥ 12kV/mm
    High Light:

    polyester sheets


    glass reinforced polyester sheet

    DIN5510 Certification red GPO3 Fiberglass Sheet , Polyester Sheet EN45545 certification good fire retardant

    Product Description:
    HC-GPO3 Sheet(Red,White,Brown)Series is rigid laminated sheet made of heat pressing which composed of e-class glass-mat reinforced unsaturated polyester and inorganic filler binder.

    GPO-3 Glossy sheet has excellent mechanical strength and automatic processing .It can be used extensively in low & middle voltage electrical equipments as insulating structures such as circuit breaker, switchgear, transformer, DC motor, AC contactor,converter,inverter & explosionproof apparatus etc. ;
    automotive industry field etc. In electrical Apparatus: making of phase & end barriers, contact terminal supports, terminal plate, insulating supports, bus bar supports and mounting panels in switchgear;
    arcchute plate, arc extinguishing cover & cylinder in circuit breaker and signal panels in other types of electrical apparatus; and electric melting furnace insulations.
    In electrical motor: making of armature parts, cover plate,slot wedge, stator, gasket,shims,carbon brush etc.


    Product Advantages:

    Beard to draft the country standard,have earned six patents

    Excellent Arc Resistance(Arc Resistance≥180 S)

    Excellent Track Resistance(CTI≥600V)

    Excellent Heat Resistance(Class F)

    Excellent Thermal Impact(Temp. Index: -273℃ to +155℃)

    Excellent Fire Retardant(UL 94 V-0 Grade)

    Excellent Mechanical Strength and Automatic Machining

    Low Smoke,Halogen Free Products(NF-F16-101/102)

    RoHS,Reach Certified products

     DIN 5510 Certification GPO3  Red Laminate Sheet , Fiberglass Plate Sheet 0


    Hong Cheng Grade HC-GPO3
    IEC 893 / EN 60893 Grade UP GM 203
    DIN 7735 Grade HM 2471
    ANSI (NEMA) Grade NEMA LI-1 GPO-3
    Items Test Method Unit Typical Values
    Physical Properties Color Visual inspection ---- Red/White/Brown/Grey
    Specific Gravity IEC 60893-2:2003 g/cm3 1.95-2.05
    Water absorption ISO62:2008 % ≤0.5
    Mechanical properties Tensile Strength IEC 60893-2:2003 Mpa ≥130
    Compressive strength IEC 60893-2:2003 ≥300
    Flexural Strength IEC 60893-2:2003 ≥180
    Impact strength IEC 60893-2:2003 KJ/m2 ≥60
    Electrical properties Volume Resistivity IEC 60093:1980 Ω·m ≥ 1.0 x 1010
    Surface Resistivity IEC 60093:1980 Ω ≥ 1.0 x 1012
    Electric Strength ┴ IEC 60893-2:2003 kV/mm ≥ 12
    Breakdown Voltage // IEC 60893-2:2003 kV/25mm ≥ 80
    Arc Resistance IEC 61621:1997 sec ≥180
    PTI Proof Tracking Index PTI IEC 60893-2:2003 --- ≥600
    Dielectric Constant IEC 60893-2:2003 --- 4.0-5.0
    tgδ Dissipation Factor IEC 60893-2:2003 --- ≤0.03
    Thermal properties Coefficient of Thermal Expansion ASTME 228-11 1/K ≤2x10-5
    Temperature Index IEC 60085:2004 155
    Flame Resistance performance Oxygen Index ISO 4589-2:1996 %O2 ≥ 30
    Flame Resistance IEC 60893-2:2003 --- V-0
    Toxicant(Emission halogen etc.) E662 --- Low
    Other properties The anti microbial properties of bacteria G21-G22 --- good

    Our company is located in Xiang’an manufacture base of Xiamen Special Economic Zone.It is a national hi-tech enterprise with the ability to R&D,production,sale and further processing,we has became the solver of electric insulation technology project .We have more than one hundred machines including CNC and Digital controlled lathe.every kinds of Bending machine,Punching machine,have establish the completely production chain of design and precision further processing .We are the only modernization company in the country which is totally operated by Numerical control in respect of material production and the process for non-metallic insulating spare parts.All of the products have gained the UL certification of the USA,The French national standard certification,CEMT,RoHS,Reach and many national& international authoritative organization certification.
