Low Water Absorption Gpo3 Sheet / Fiberglass Board Sheets In Switch Cabinet

Low Water Absorption Gpo3 Sheet / Fiberglass Board Sheets In Switch Cabinet

    • Low Water Absorption Gpo3 Sheet / Fiberglass Board Sheets In Switch Cabinet
    • Low Water Absorption Gpo3 Sheet / Fiberglass Board Sheets In Switch Cabinet
    • Low Water Absorption Gpo3 Sheet / Fiberglass Board Sheets In Switch Cabinet
  • Low Water Absorption Gpo3 Sheet / Fiberglass Board Sheets In Switch Cabinet

    Product Details:

    Payment & Shipping Terms:

    Minimum Order Quantity: 100KGS
    Price: 3-4USD
    Packaging Details: PALLET
    Delivery Time: 5-7 WORK DAY
    Payment Terms: T/T, Western Union
    Supply Ability: 400TONS PER MONTH
    Contact Now
    Detailed Product Description
    Raw Material: Glass Fiber Mat And Polyester Resin Color: Red And White
    Size: 1000*1200/1230*2100mm CTI: 600
    ARC: 183S Name: Low Water Absorption Gpo3 Sheet / Fiberglass Board Sheets In Switch Cabinet

    Low water absorption GPO-3 sheet used in Switch cabinet



    Product Introduction:

    GPO-3 laminated sheet was made of fiberglass and polyester resin the fiberglass was impregnated in polyester resin with the aluminium hydroxide material and then press under the high temperature & pressure by machine. It has the performance of very low water absorption , the water absorption is below 0.005% .

    As we known , water will caused insulation performance lower . It will damage the electrical equipments once the insulation material with higher water absortion . For example , metro is always underground . Underground means humidity range is widely . If the property of absorption resistance is not good enough , it will be very easy fault and even scrap for the whole electrical equipment . As soon as we know , the main filler material of GPO-3 sheet are calcarea carbonica or aluminium hydroxide . Our GPO-3 material uses aluminium hydroxide as the filler material although production cost is higher than calcarea carbonica , but the warter absorption is lower , it will more safety when the equipment running In This Working Environment .



    Feature of product:

    1. It is very high mechanical property material , the tensile can reach to more than 160MPA according to IEC test standard .
    2. This GPO-3 material is excellent Electrical Performance material , the arc resistance of it reaches more than 180 seconds.
    3. It is the green product , it has been recognized by latest revision RoHs and Reach.
    4. It is the customized product which can be machined as per client’s requipments , it can be machined by CNC with very high accuracy class .
    5. Working temperature range is very widely , the temperature index of this materials is from -270 to 155 degree centigrade , it can adjust to very low and high temperature when running.
    6. It has the advantages on low smoke material and halogen free which is more safety when running in the assembly occupancies.

    Low Water Absorption Gpo3 Sheet / Fiberglass Board Sheets In Switch Cabinet



    Low Water Absorption Gpo3 Sheet / Fiberglass Board Sheets In Switch Cabinet

    Application of product:

    1. GPO-3 laminated sheet and machined parts are application to Switch cabinet in rail traffic , such as metro , CRH train , high speed rail etc. most of them are used as the insulation sheet , insulation support , bus-bar clamp and cover plate in Switch cabinet , because it has very excellent properties on absorption resistance , electrical and mechanical . The most important is good arc performance , further more the materials with the advantages with low smoke , non-poisonous , halogen free and good fire resistance with EN45545 certificate .
    2. As we know , it is very important to rail traffic of the safety , Railway traffic is a highly intensive place for people , arc performance is very very important , is the arc is not good enough , the material will be break down by the arc , it will cause the fire hazard . In other way , the low smoke , non-poisonous and good fire resistance are top important performance to ensure safety running. Actually , most of the train manufacturers in China have already contacted with us to supply this material , we have so rich experiences on it .
