Air Gap UPGM 203 Insulation Sheet With Reach And RoHs Certified Use In Transformer

    • Air Gap UPGM 203 Insulation Sheet With Reach And RoHs Certified Use In Transformer
    • Air Gap UPGM 203 Insulation Sheet With Reach And RoHs Certified Use In Transformer
    • Air Gap UPGM 203 Insulation Sheet With Reach And RoHs Certified Use In Transformer
    • Air Gap UPGM 203 Insulation Sheet With Reach And RoHs Certified Use In Transformer
  • Air Gap UPGM 203 Insulation Sheet With Reach And RoHs Certified Use In Transformer

    Product Details:

    Place of Origin: China
    Brand Name: Hongcheng
    Certification: UL(E344098)/RoHS 2.0 /Reach/SGS
    Model Number: UPGM203

    Payment & Shipping Terms:

    Minimum Order Quantity: 500kgs/shipment
    Price: 3.0-3.8 USD/kg
    Packaging Details: pallet
    Delivery Time: 7-10 days
    Payment Terms: T/T
    Supply Ability: 300tons/Month
    Contact Now
    Detailed Product Description
    Product Name:: Red UPGM203 Nema Standard: GPO-3
    Water Absorption: <0.005% Inflaming Retarding: V-0
    Tensile Strength: >162Mpa Vertical Compression Strength: 490Mpa
    CTI: >600 Heat Resistance: F Class



    upgm203 used as Air gap sheet with Reach and RoHs certified used in transformer


    Product Introduction:

    Air gap sheet was made from glass fiber mat and polyester resin , it is a glass reinforced thermoset polyester sheet material.

    Electric/ mechanical properties of this composite are very excellent , it has quite strong, dimensionally stable and impact resistant of mechanical properties. Meanwhile ,it has many advantages on properties , such as good properties on flame, arc and track resistance. To meet environmental requirement , the material has reached requirement of ROHS/REACH .In order to meet the requirement for exporting to Europe and North America , the material has certificated by UL. At present ,we are exporting this material to transformers manufacturers all over the world .



    Feature:



    It is environmental protection material , very little effect to the environmental when running on the tramsformers
    It is halogen free product and green product , no effect to the human bodies .
    Very stable of the strength such as tensile&bending when running on high or low temperatures

    It is the fire resistance material and low smoke material .





    Thickness range :2mm-60mm



    Sheet Size:1000mm*1200mm  or 1230mm*2100mm


    Hong Cheng Grade HC-GPO3
    IEC 893 / EN 60893 Grade UP GM 203
    DIN 7735 Grade HM 2471
    ANSI (NEMA) Grade NEMA LI-1 GPO-3
    Items Test Method Unit Typical Values
    Physical Properties Color Visual inspection ---- Red/White/Brown/Grey
    Specific Gravity IEC 60893-2:2003 g/cm3 1.95-2.05
    Water absorption ISO62:2008 % ≤0.5
    Mechanical properties Tensile Strength IEC 60893-2:2003 Mpa ≥130
    Compressive strength IEC 60893-2:2003 ≥300
    Flexural Strength IEC 60893-2:2003 ≥180
    Impact strength IEC 60893-2:2003 KJ/m2 ≥60
    Electrical properties Volume Resistivity IEC 60093:1980 Ω·m ≥ 1.0 x 1010
    Surface Resistivity IEC 60093:1980 Ω ≥ 1.0 x 1012
    Electric Strength ┴ IEC 60893-2:2003 kV/mm ≥ 12
    Breakdown Voltage // IEC 60893-2:2003 kV/25mm ≥ 80
    Arc Resistance IEC 61621:1997 sec ≥180
    PTI Proof Tracking Index PTI IEC 60893-2:2003 --- ≥600
    Dielectric Constant IEC 60893-2:2003 --- 4.0-5.0
    tgδ Dissipation Factor IEC 60893-2:2003 --- ≤0.03
    Thermal properties Coefficient of Thermal Expansion ASTME 228-11 1/K ≤2x10-5
    Temperature Index IEC 60085:2004 155
    Flame Resistance performance Oxygen Index ISO 4589-2:1996 %O2 ≥ 30
    Flame Resistance IEC 60893-2:2003 --- V-0
    Toxicant(Emission halogen etc.) E662 --- Low
    Other properties The anti microbial properties of bacteria G21-G22 --- good

     Air Gap UPGM 203 Insulation Sheet With Reach And RoHs Certified Use In Transformer

    upgm203 fiberglass Sheet  is used extensilvely in rail traffic,There are many modules for the use of insulation materials in rail transit, modules of motor and traction motor, module equipment and interior decoration.On safety performance for this kind of civil transport have quite high demand, need fire report, flame retardant grade should be V0, heat resistance grade should be above F, even C grade requirement of heat resistance, besides the material itself needs certain mechanical strength and electrical strength. The commonly used materials in rail traffic are upgm203  sheet
